(PartNumber) EP2C8T144C8N
(QTY) 1500 pieces IN STOCK
(Brand) ALTERA
(Package) QFP-144,New&Original
(DC.) 11+RoSH

EP2C8T144C8(EP2C8T144C8N),QFP-144 pins, Manufacturer: ALTERA, Quantity: 1500pcs IN STOCK, UNIT PRICE: US$11.50 each.(Email or Call us for the CURRENT price)

100% NEW & ORIGINAL factory sealed. 360 days quality GUARANTEE!

Distributor: Excellent Integrated System LIMITED



Tel.: 00852-30777742


The Altera EP2C8T144C8N is an enhanced configuration device. It is a single-device, high-speed, advanced configuration solution for very high-density FPGAs. The core of EP2C8T144C8N is divided into two major blocks: a configuration controller and a flash memory. The flash memory of EP2C8T144C8N is used to store configuration data for systems made up of one or more Altera FPGAs. Unused portions of the flash memory can be used to store processor code or data that can be accessed via the external flash interface after FPGA configuration is complete.
EP2C8T144C8N absolute maximum ratings: (1)Supply voltage: -0.2 to 4.6 V With respect to ground; (2)DC input voltage: -0.5 to 3.6 V With respect to ground; (3)DC VCC or ground current: 100 mA; (4)DC output current, per pin: -25 to 25 mA; (5)Power dissipation: 360 mW; (6)Storage temperature No bias: -65 to 150 ℃; (7)Ambient temperature Under bias: -65 to 135 ℃; (8)Junction temperature Under bias: 135 ℃.
EP2C8T144C8N features: (1)Contains 4-, 8-, and 16-Mbit flash memories for configuration data storage: On-chip decompression feature almost doubles the effective configuration density; (2)Standard flash die and a controller die combined into single stacked chip package; (3)External flash interface supports parallel programming of flash and external processor access to unused portions of memory.

EP2C8T144C8N block diagram

Datasheet download URL:

Quantity Available 1500 pcs IN STOCK
Manufacturer Altera
Manufacturer Part Number EP2C8T144C8N
Description IC CYCLONE II FPGA 8K 144-TQFP
Lead Free Status / RoHS Status Lead free / RoHS Compliant

Datasheets Cyclone II Device Family
Product Photos 144-TQFP
Product Training Modules Three Reasons to Use FPGA's in Industrial Designs
Standard Package 60
Category Integrated Circuits (ICs)
Family Embedded - FPGAs (Field Programmable Gate Array)
Series Cyclone® II
Number of Logic Elements/Cells 8256
Number of LABs/CLBs 516
Total RAM Bits 165888
Number of I /O 85
Number of Gates -
Voltage - Supply 1.15 V ~ 1.25 V
Mounting Type Surface Mount
Operating Temperature 0°C ~ 85°C
Package / Case 144-LQFP
Supplier Device Package 144-TQFP (20x20)
Catalog Page 643 (US2011 Interactive)
643 (US2011 PDF)
Other Names 544-1666
